HOLLYLAND PYRO S 4K HDMI/SDI WIRELESS VIDEO TRANSMISSION SYSYEM

Hollyland Pyro S 4K HDMI/SDI Wireless Video Transmission System

Take your video production to the next level with the Hollyland Pyro S 4K HDMI/SDI Wireless Video Transmission System, engineered for professional filmmaking, live events, and ENG/EFP workflows. This versatile system includes one transmitter and four receivers, allowing multiple users to monitor UHD 4K30 video simultaneously. With an impressive line-of-sight transmission range of up to 400 meters (1300 feet) and ultra-low latency of just 50ms, Pyro S delivers smooth, high-quality video for demanding productions. Featuring HDMI and SDI inputs/outputs, Auto Dual-Band Hopping (2.4GHz & 5GHz), and omnidirectional high-gain antennas, it ensures stable signals even in crowded frequency environments. The lightweight magnesium alloy shell enhances durability and heat dissipation, while UVC compatibility and RTMP streaming support seamless live broadcasts to platforms like YouTube, Zoom, Twitch, and TikTok. Preset grouping, smart channel scanning, and a bright full-color LCD simplify setup and monitoring, making Pyro S the ultimate wireless video solution for filmmakers, broadcasters, and content creators seeking reliable, long-range, and professional-grade performance.

Key Features:

• Professional Wireless Video Transmission – Transmit UHD 4K30 video up to 400m (1300′) line-of-sight with minimal 50ms latency.

• Multi-User Monitoring – One transmitter supports up to four receivers simultaneously for flexible on-set monitoring.

• HDMI & SDI Support – Compatible with both HDMI 1.4b and 3G-SDI inputs/outputs for maximum versatility.

• Dual-Band Auto Frequency Hopping – Operates on 2.4GHz & 5GHz bands with intelligent channel scanning to reduce interference.

• UVC Plug-and-Play – Seamless connection to computers and devices for live streaming or video conferencing.

• RTMP Streaming – Broadcast directly to platforms like YouTube Live, Twitch, Zoom, and TikTok.

• Durable & Lightweight – Magnesium alloy shell provides heat dissipation, portability, and robustness.

• Smart Channel Scan & Full-Color LCD – Easily monitor transmission status, battery levels, frequency, and channels.

• Flexible Power Options – Supports DC, L-Series batteries, and USB-C (5-12V) for stable and continuous operation.

• Preset Grouping & Easy Setup – Simplifies pairing between transmitter and receivers for fast deployment.

• Long-Distance Broadcast Mode – Extended range up to 650′ for up to four receivers and two mobile devices in broadcast mode.

• Superior Image Quality – 4K30 via HDMI and 1080p60 via SDI for crisp, detailed, professional visuals.

• Lightweight & Compact – Transmitter/receiver weigh just 207g each, ideal for field production and stabilizer use.

• Temperature Resistant – Operates reliably between -10°C to 45°C, perfect for diverse shooting environments.

Specifications:

• Antennas: 3x RP-SMA Male (Transmitter/Receiver)

• Video Input: HDMI 1.4b, BNC (3G-SDI)

• Video Output: HDMI 1.4b, BNC (3G-SDI)

• Audio: HDMI/SDI embedded

• Power Input: 6–16 VDC, USB-C (5-12V), L-Series battery option

• Wireless Range: 396m LOS (standard), 198m LOS (broadcast)

• Frequency Range: 2.412–2.484 GHz, 5.15–5.85 GHz

• Latency: 50 ms

• Wireless Compression: Uncompressed

• Dimensions: 112 x 71 x 34 mm

• Weight: 207 g (per unit)

In the box:

• Hollyland Pyro S 4K HDMI/SDI Wireless Video Transmission System
• Hollyland Pyro S 4K HDMI/SDI Wireless Video Receiver
• Hollyland Pyro S 4K HDMI/SDI Wireless Video Transmitter
• 7 x Hollyland Paddle Antenna for Pyro Series (2.4/5 GHz)
• Hollyland Rotatable Cold Shoe Adaptor Mount for Wireless Unit
• USB-C OTG Adaptor
• Hollyland DC Power Adaptor for Pyro S (12 VDC, 2A)
• Limited 1-Year Warranty
